Medical Gas Installation
NFPA 99 certified medical gas systems for dental, medical, and surgical facilities across Oklahoma and Texas.
UDGOK provides ASSE 6010 certified medical gas installation for dental offices, surgical centers, and healthcare facilities across Oklahoma. We install oxygen, nitrous oxide, medical air, and vacuum piped systems to NFPA 99 standards, with third-party ASSE 6030 verification testing. Medical gas installation costs range from $15,000 to $80,000+ depending on system complexity and facility size.
Precision Execution
Medical gas installation is a life-safety system requiring ASSE 6010 certified installers and strict adherence to NFPA 99. UDGOK's medical gas division installs, tests, and certifies complete piped gas systems for any size facility — from a 3-operatory dental office to a multi-suite medical office or ambulatory surgical center.
Discuss Your Project →What We Deliver
Oxygen Systems
Bulk oxygen supply, LOX systems, H-cylinder manifolds with automatic changeover and alarm panels.
Nitrous Oxide
N2O piping systems with zone valve boxes, WAGD (waste anesthetic gas disposal), and scavenging.
Medical Air
NFPA 99-compliant dental air or medical-grade air compressors with filtration and dew point monitoring.
Vacuum Systems
Wet and dry vacuum systems sized for procedure counts, including dental high-volume evacuation.
Alarm Systems
Master alarm panels, area alarm panels, and zone valve assemblies with NFPA-required features.
Testing & Certification
ASSE 6030 verifier testing, cross-connection testing, and third-party certification documentation.
How much does medical gas installation cost?
Medical gas installation costs depend on the type of facility, number of outlets, and gas types required:
| Facility Type | Typical Gas Types | Cost Range |
|---|---|---|
| 3–6 Chair Dental Office | Air, Vacuum, N2O (optional) | $15,000–$35,000 |
| Large Dental / Oral Surgery | Air, Vacuum, O2, N2O, WAGD | $35,000–$60,000 |
| Medical Office (no gases) | Medical Air, Vacuum only | $8,000–$20,000 |
| Ambulatory Surgery Center | O2, N2O, Medical Air, Vacuum, WAGD | $50,000–$150,000+ |
Costs include copper piping, zone valve boxes, outlet stations, alarm panels, and ASSE 6030 third-party verification testing. Source equipment (compressors, vacuum pumps, cylinder manifolds) is additional.
What certifications are required for medical gas installation?
Medical gas installation is heavily regulated. NFPA 99 (Health Care Facilities Code) requires:
- ASSE 6010: Certification for medical gas installers — required for anyone brazing medical gas piping
- ASSE 6020: Certification for medical gas inspectors (used during construction oversight)
- ASSE 6030: Certification for medical gas verifiers — required for final testing and certification
- ASSE 6040: Certification for medical gas maintenance personnel
All UDGOK medical gas installers hold current ASSE 6010 certification. We engage independent ASSE 6030 certified verifiers for third-party testing — this is required by NFPA 99 Section 5.1.12 and cannot be performed by the same entity that installed the system.
What testing is performed on medical gas systems?
NFPA 99 requires comprehensive testing before any medical gas system is placed in service. The ASSE 6030 verification includes:
- Standing pressure test: 24-hour test at 150% of system operating pressure to verify joint integrity
- Cross-connection test: Verify each outlet delivers the correct gas and only that gas
- Flow test: Confirm adequate flow rates at the most remote outlets
- Purity test: Particulate count and dew point testing per CGA G-4.1 standards
- Alarm verification: Test all master, area, and zone alarm functions
- Labeling verification: Confirm NFPA-required labels on all outlets, valves, and piping
UDGOK provides complete test documentation and third-party verification certificates that satisfy OSDH (Oklahoma State Department of Health) and Joint Commission requirements.
The
Process
Our proprietary construction methodology eliminates surprises, protects your budget, and accelerates your opening date.
Discovery & Analysis
We comprehensively assess your clinical program, target real estate, zoning conditions, and specific regulatory requirements.
Design & Engineering
Our teams coordinate full construction documents with integrated real-time cost tracking to prevent ballooning budgets.
Construction Execution
Self-performed mechanical systems and rigorous site management ensure total quality control and adherence to schedule.
Commissioning & Turnover
We validate all medical systems, manage inspections, and fully orient your administrative staff to the new facility.
